U0200STD

(Ratios = 1:1,1.824:1,3.039:1,4.012:1)
(Input Shaft Diameter = 1.00” - Output Shaft Diameter = 1.00”)

The U0200STD is one of the most popular Drive-All models. It offers a compact footprint and can transmit up to 2 Horsepower at 1800 rpm. It is assembled with a lightweight aluminum housing and is less than 15” long with a width just over 9”. It offers 4 different speeds and the handle can be attached on either side. The shafts of the U0200STD rotate in the same direction and the unit can be utilized as an increaser or reducer. If you would like additional information about the U0200STD please contact a Drive-All Sales Engineer at 800-689-3400 or visit the Drive-All web-site at: www.driveallmfg.com

Previous applications include: Portable Wire Winders, Fish Hatcheries, Bulk Food Processing, and Insulation Blowers


Weight: 42.00 LBS
$1,512.93

U0200STD

More Views

  • U0200STD

Horsepower and Torque Rating

Input Speed

*Max. Input Hp**

Max. Input Torque

100

0.57

200

1.14

300

1.71

400

2.00

500

2.00

600

2.00

700

2.00

800

2.00

900

2.00

1000

2.00

1100

2.00

1200

2.00

1300

2.00

1400

2.00

1500

2.00

1600

2.00

1700

2.00

1800

2.00

*All gearboxes are rated at 1800 rpm
** Excessive overhung load can dramatically affect gearbox capabilities and performance
Catalog Horsepower Calculator
